Fiber Flying Laser Printer

Technical Parameters

Body material:  All aluminum structure

Laser source: Fiber laser source

Power supply:  100~240V / 50~60Hz AC

Laser powe:  ≥30W

Total power:  ≤700W

Laser wavelength:  1064nm

File format:  BMP/DXF/JPEG/PLT

Marking speed:  ≤10000mm/s

Graphics file format:  PLT format vector file input/output

Marking line width:  0.01-0.1mm

Peripheral interface:  USB/Serial & Ethernet communication

Marking depth:  0.01-0.03mm

Screen:  10.2 inch HD screen

Marking range:  110mm x 110 mm (Standard)

Product line speed:  0-150m/min

Marking accuracy:  ≤0.01mm

Repeat accuracy:  ≤0.01mm

Font type:  Single-line font/double-line font/bit matrix font

Marking lines:  Edit freely within the marking range

Cooling method:  Air cooled

Positioning mode:  Red light focus, red light auxiliary preview

Marking line type:  dot matrix, vector

Laser working life: 100,000 hours

Protection degree:  IP54

Environmental:  -10°C-45°C(no freezing)/10%-85%(non-condensing)

Net weight: 28Kg(host) / 29.2Kg(stand)

Package Size:  96cm*46cm*47cm(host) / 133cm*35cm*27cm(stand)

Print content:  variable data(Serial number, date, counter, shift), graphic element(Point, Line, Arc Text, Rectangle, Circle)

System language:  Chinese, English, Spanish, Russian, Arabic, Portuguese, French, Thai, Japanese, Korean, ec.
